CONNECTORS & RECEPTACLES
DIN PLUGS AND RECEPTACLES PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
DIN PLUGS AND RECEPTACLES (continued)
STRAIGHT CORD PLUG with Flush Socket Insert
TYPE 06AL5F – TYPICAL
Female plug with ground contact. Diecast metal shell,
nickel-plated. Two contact plug, Part number 04AL2F includes
a break circuit switch (1-B) which is opened by engaging the
insulated switch actuator of the mating plug or receptacle.
Flexible black strain relief.
STRAIGHT CORD PLUG with Lock Flange
TYPE 06EL5F – TYPICAL
Female plug with ground contact. Lock flange designed to
accept 30° lockring. Insert screw firmly holds insert assembly in
shell. Flexible black strain relief with 7/32" diameter cable entry.
Heavy duty cable clamp.
.216
5.5
.393
10.0
.216
5.5
2.24
57.0
.456
11.6
.622
15.8
0.51
Stain Relief
ORDERING INFORMATION
1.22
31.0
1.3
ORDERING INFORMATION
Part Number
Description
Contact Arrangement
Part Number
Description
Contact Arrangement
? 06AL5F
? 13AL5F
? 13AL6F
5
5
6
contacts at 180°
contacts at 240°
contacts at 240°
F
E
G
? ? 06EL5F
13EL5F
? 15EL8F
5 contacts at 180°
5 contacts at 240°
8 contacts at 270°
F
E
N
? 15AL7F
? 15AL8F
7
8
contacts at 270°
contacts at 270°
H
N
RECEPTACLE with Extended Shell
TYPE 57KD3M – TYPICAL
ORDERING INFORMATION
Male receptacle, 3 pins, with ground key-rib. Diecast
extended shell and flange for chassis or panel mounting.
Turret terminals.
Part Number
57KD3M
Description
3 pins at 180°
Pin Arrangement
2
? Available on special order only; contact Switchcraft for price and delivery.
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
